• Definition. A retaining wall is a structure designed and constructed to resist the lateral pressure of soil, when there is a desired change in ground elevation that exceeds the angle of repose of the soil. A basement wall is thus one kind of retaining wall. But the term usually refers to a cantilever retaining wall,...

The material cost to install a cinder block wall is typically between $3 and $5.50 per square foot, which includes the cost of the blocks themselves, mortar and structural reinforcement.

These walls need a drainage system regardless of the wall height. If there are poor draining soils such as clay behind the wall, there needs to be drainage incorporated the wall system. Clay when wet is very weak, so it is essential to provide a way for water to escape from behind the wall.Oct 11, 2020

On average, building a retaining wall costs $23 per square foot. For the more budget-conscious, retaining wall prices average at $19 per square foot. On the upper end, retaining wall costs are around $50 per square foot.Sep 8, 2021

Generally speaking, the California average cost for a retaining wall is anywhere between $300-$900 per linear foot.Apr 16, 2021

• Divide the width of the wall in inches by the width of the block and round up, this is the number of columns. Divide the height of the wall in inches by the height of the block and round up, this is the number of rows. If the top row will be a cap block then the number of cap blocks needed is the number of columns.

• Remember in the first example, the retaining wall was 10 feet high and 100 feet in length. All you do is multiply L x H = SF in this example; the answer is 1,000 square feet (SF). To find the number of 8" x 8" x 16" block required, you must determine the square footage of one CMU which is .89 SF per block.

• Estimate the number of concrete blocks needed by multiplying the area by 1.125. For example, if the area is 120 square feet, you need about 135 concrete blocks. This is an estimate for the standard block dimension, which is 8 inches by 16 inches.

We understand, however, that you might be in the mood to do the maths yourself, and hereby present you with all the necessary equations! The number of retaining wall blocks is calculated using the following formulas: number of columns = wall length / block length (rounded up if not a full number)

To estimate the total number of retaining wall blocks, you’ll first need to calculate the number of rows and columns needed for the wall. Start by measuring the wall’s width and height. Most experts suggest embedding the first course of blocks below grade about 10% of the wall height to support it correctly.

To calculate the amount of blocks you require for the entire wall YY x ZZ = Amount of blocks you require eg. Heathstone Grande Block dimensions: 440mm long x 162mm high x 270mm deep. Wall to be 25 Lineal Metres and 1metre high. Blocks per lineal metre 1000mm/ 440mm (length of block.) = 2.28

It is crucial for keeping the wall steady, as well as making sure it does not get eroded by water. It is recommended do use a granular material such as gravel, which is what we chose for the retaining wall calculator. Declare the backfill area's height, length and thickness. Height and length typically correspond to the wall's height and length.

Base width = 1/2 to 1/3 of the height of the wall. Base thickness = 1/8 of the height of the wall but not less than 12 inches. Stem thickness = 6 inches + ¼ inch for each foot of wall height.Jan 13, 2014

Use the formula.

Calculating the volume for concrete requires using three dimensions: length times width (which is area) times the height (thickness) or L x W x H. If you are using feet as your standard unit of measurement, this formula will give you the volume of concrete in cubic feet.

Measure the width of the wall, measuring from the back of the blocks to the dirt wall. Determine the height of the wall. Multiply the length, width and depth of the wall. Divide the number by 27 to get the cubic yards of gravel required for your wall.Sep 26, 2017

On average, building a retaining wall costs $23 per square foot. For the more budget-conscious, retaining wall prices average at $19 per square foot. On the upper end, retaining wall costs are around $50 per square foot.Sep 8, 2021

For level top surface, the base width of wall is determined in the same way as the cantilever type retaining wall. However, in counterfort type wall the base width is kept from 0.5H to 0.7 H, in which H is the total height of the retaining wall.

To construct a footing for a dry-stacked retaining wall, excavate a trench that is 5 to 7 inches deep plus 1 inch for every 8 inches of planned wall height. Lay 4 to 6 inches of course gravel in the trench and tamp it down, checking for level regularly and making adjustments as needed.

Most retaining walls, whether load-bearing or not, average between 3 and 4 feet in height. As a general rule, you do not want to build any sort of structure over 4 feet in height without including some type of structural support within.

• Choose gravel that has stones sized between 1/2-inch and 3/4-inch.
• Fill the trench with a 2- to 3-inch layer of gravel.
• Use a rake to ensure the stones are evenly distributed.
• Tamp the base with your tamper to make sure it’s evenly compacted.

• Stackable Concrete Blocks. Stackable stones are made of concrete,with a decorative finish on the front and a lip on the back. ...
• Materials Needed. Estimating the number of blocks you’ll need is tough. ...
• Layout and Planning. ...
• Digging the Trench. ...

• Select the retaining wall location. Minimize soil excavation and backfill. ...
• Determine retaining wall height and geometry. Calculate the retaining wall height at its tallest position. ...
• Evaluate structural requirements. If geogrid is required,see the geogrid charts for approximate grid length.
• Calculate the total wall structure. ...
